SANSYU FINETOOL
Sansyu Finetool is the basement for the precision work of all companies members of our group.
Molds made at Finetool are the media that reflect our technology & craftmanship,
and we are proud of every mold that comes out from this facility.
Company Outline
Company name
SANSYU FINETOOL Co.,Ltd.
Established
August 28th, 1967
Headquarters
4-1-55 Hieda-cho, Takahama-city, Aichi, 444-1321 JAPAN
Directors
President : Munetaka Kamiya
Business area
Manufacturing of precision molds and dies
Employees
74
Contact
TEL : +81-566-53-1781
FAX : +81-566-52-6561
ISO Certifications
Certifications
Originally Certified in
ISO 9001
Nov. 2005
ISO 14001
Apr. 1999
Interior view of the tool factory
Heat treatment room Optical Profile Grinder
Machining Center Precision Machining Center
WED machining line (oil media) Jig Grinder
Product Sample by Wire cut EDM
Made only by WEDM process
High precision diamond turning lathe
EDM process line Automated work changer for EDM
SANSYU - made molds
A consistent tool develoment system (design & manufacturing) allows us to satisfy customer's requirements with innovative solutions, fit for each particular product.
Slide-type mold for Overmolding Mold with multiple slide directions Cassette-type molds
Facilities
Main processing facilities
Name Model Maker Number of machines Capacity X x Y x Z Feature
Micro Milling Machine for Ultra Precision Performance iQ300 Makino 1 220 x 220 x 90 45,000rpm
Micro Milling Machine for Ultra Precision Performance HYPER-2J Makino 1 150 x 100 x 100 40,000rpm
Vertical machining center YMC650+Mi16 YASDA PRECISION TOOLS 1 200 x 200 x 225
Vertical machining center V33i-5XB Makino 1 250 x 250 x 150 40,000rpm
High-Precision High-speed,Micro Fine Machining Center MEGA-360 ROKU-ROKU SANGYO 1 150 x 150 x 150 AWC（Original）
32
Precision Machining Center V22 Makino 2 100 x 100 x 120 AWC 60
Hard Milling Machine V33i Makino 2 230 x 230 x 85 40,000rpm
Horizontal Machining a61nx Makino 1 450 x 450 x 100 AWC 2 tables x 2 sides
Grinding Machine PSG3AD Okamoto Machine Tool Works 1 130 x 250 x 190
CNC Grinding Machine MEISTER G2V TECNO WASINO 2 140 x 350 x 160
CNC Ultra Precision Form Grinding Machine TECHSTER D3 TECNO WASINO 1 400 x 600 x 220
CNC Ultra Precision Form Grinding Machine MEISTER V3 TECNO WASINO 2 150 x 350 x 190
CNC Optical Profile Grinder GLS-521 TECNO WASINO 2 200 x 150 x 100
CNC Jig Grinder S40-DR HAUSER 1 600 x 400 x 40
CNC Jig Grinder 3SMO HAUSER 1 350 x 200 x 40
CNC Jig Grinder 3GBM MITSUI SEIKI KOGYO 1 400 x 250 x 50
CNC Precision Cylindrical Grinding Machine S30 Lean PRO STUDER 1 Φ33 x 100
CNC Precision Cylindrical Grinding Machine ECO 650 STUDER 1 Φ33 x 150
High speed Die sinking EDM Agie Charmilles FORM200 GF Machining Solutions 2 300 x 200 x 120 AWC 5
Electrical Discharge Machine EA12V Mitsubishi Electric 1 300 x 300 x 200
Electrical Discharge Machine VX10 Mitsubishi Electric 1 350 x 250 x 200
Electrical Discharge Machine MA2000M + EROWA system Mitsubishi Electric 2 400 x 300 x 100 AWC 6
High performance EDM EDGE2 Makino 1 250 x 200 x 100 AWC 2
High precision Wire cut EDM Agie Charmilles CUT3000S GF Machining Solutions 1 Φ0.1 : 100 x 100 x 40
Φ0.2 : 200 x 200 x 120		 AWC 16,
Wire diameter
Φ0.1 and 0.2
Ultra-precision Wire cut EDM UPJ-2 Makino 1 50 x 50 x 3 AWC 3,
Minimum wire diameter Φ0.03
Ultra-precision Wire cut EDM UPH-2 Makino 2 Φ0.1 : 100 x 100 x 25
Φ0.2 : 150 x 150 x 40		 AWC 16,
Wire diameter Φ0.1 and 0.2
High accurate Wire cut EDM FA20P + EROWA system Mitsubishi Electric 4 200 x 200 x 70 AWC 42
Pressurized Vacuum Heat Treatment Furnace NVF30 NAKANIHON RO KOGYO 2 370 x 180 x 180
Pressurized Vacuum Heat Treatment Furnace NVF80 NAKANIHON RO KOGYO 1 400 x 260 x 380
Ultra low temperature freezer for sub-zero treatment MDF-C8V1 Panasonic 1 280 x 280 x 200
Main measuring instrument
Name Model Maker Number of machines
Digital Micro Scope VHX-7000 Keyence 1
CNC CMM Crysta Apex-776 Mitutoyo 1
CNC CMM Falcio Apex-7106 Mitutoyo 1
CNC CMM Bright-A504 Mitutoyo 1
CNC CMM Crysta Apex V544 Mitutoyo 1
Video and Multisensor Measurement Systems Smart scope ZIP300 OGP 1
Surface Roughness Tester SE1700α-18D Kosaka Laboratory 1
Measuring Microscope MM-800 Nicon 2
Profile Projectors PJ-H3000 Mitutoyo 1
Rockwell Type Hardness Testing Machines HR-100 Mitutoyo 1
Software
Name Model Maker Number of machines
TOP solid 3DCAD Kodama Corporation 11
TOP Cam 3DCAM Kodama Corporation 7
FFAUT 3DCAM Makino 1
FFCAM 3DCAM Makino 1
CAM-TOOL 3DCAM C&G Systems 2
